[MRCA] R390A dropping resistor value

[Jeep Platt]

That is fine. The mod has it physicslly located within the audio module and connected just before the filter choke.

Sent from my Verizon, Samsung Galaxy smartphone
Get Outlook for Android<https://aka.ms/AAb9ysg>
________________________________
From: mrca-bounces at mailman.qth.net <mrca-bounces at mailman.qth.net> on behalf of Bill Mellema via MRCA <mrca at mailman.qth.net>
Sent: Monday, January 26, 2026 3:48:27 PM
To: JPHutch <jphutch60bj at gmail.com>; mrca at mailman.qth.net <mrca at mailman.qth.net>
Subject: Re: [MRCA] R390A dropping resistor value

Hutch & Jeep,

I installed the resistor in the rectifiers output line, pin 5 of P111!, the B+ line.

Bill N3WM


Sent from Yahoo Mail for iPhone<https://overview.mail.yahoo.com/?.src=iOS>


On Monday, January 26, 2026, 3:38 PM, JPHutch <jphutch60bj at gmail.com> wrote:

Jeep -

Is this the correct location for the modification?

[Modification location ?]

Thanks

Hutch

On 1/24/2026 1:29 PM, Doran Platt via MRCA wrote:
OK...  the SPAWAR manual says 200-220 ohms, located in the audio module. It's inserted between the B+ input pin and the Pi section B+ filter. A Dale looks to be the type resistor. I think 10w is a bit high.
Jeep K3HVG
On 01/23/2026 9:11 PM EST Bill Mellema via MRCA <mrca at mailman.qth.net><mailto:mrca at mailman.qth.net> wrote:


Great….thanks Jeep

Bill N3WM


Sent from Yahoo Mail for iPhone<https://overview.mail.yahoo.com/?.src=iOS>


On Friday, January 23, 2026, 7:30 PM, Jeep Platt <jeepcomms at outlook.com><mailto:jeepcomms at outlook.com> wrote:

Bill, I have the Navy book that shows solid-state rectifiers.  I will look it up in the morning...
Jeep K3HVG

Sent from my Verizon, Samsung Galaxy smartphone
Get Outlook for Android<https://aka.ms/AAb9ysg>
________________________________
From: mrca-bounces at mailman.qth.net<mailto:mrca-bounces at mailman.qth.net> <mrca-bounces at mailman.qth.net><mailto:mrca-bounces at mailman.qth.net> on behalf of Bill Mellema via MRCA <mrca at mailman.qth.net><mailto:mrca at mailman.qth.net>
Sent: Thursday, January 22, 2026 8:23:33 PM
To: Military Radio Collectors Association <mrca at mailman.qth.net><mailto:mrca at mailman.qth.net>
Subject: [MRCA] R390A dropping resistor value

Guys,

I'm in the process of solid stating the power supply on a R390A. I need the value of the series resistor listed in the field change.

If anyone can help, I would appreciate it.

Best 73's

Bill N3WM
