[MRCA] R390A dropping resistor value

[Bill Mellema]

Hutch & Jeep,
I installed the resistor in the rectifiers output line, pin 5 of P111!, the B+ line.
Bill N3WM


Sent from Yahoo Mail for iPhone


On Monday, January 26, 2026, 3:38 PM, JPHutch <jphutch60bj at gmail.com> wrote:


Jeep -

Is this the correct location for the modification?



Thanks

Hutch
 On 1/24/2026 1:29 PM, Doran Platt via MRCA wrote:


 OK...  the SPAWAR manual says 200-220 ohms, located in the audio module. It's inserted between the B+ input pin and the Pi section B+ filter. A Dale looks to be the type resistor. I think 10w is a bit high.    Jeep K3HVG
  On 01/23/2026 9:11 PM EST Bill Mellema via MRCA <mrca at mailman.qth.net> wrote:          Great….thanks Jeep      Bill N3WM


 Sent from Yahoo Mail for iPhone


On Friday, January 23, 2026, 7:30 PM, Jeep Platt <jeepcomms at outlook.com> wrote:

    Bill, I have the Navy book that shows solid-state rectifiers.  I will look it up in the morning...   Jeep K3HVG         Sent from my Verizon, Samsung Galaxy smartphone
 Get Outlook for Android     From: mrca-bounces at mailman.qth.net <mrca-bounces at mailman.qth.net> on behalf of Bill Mellema via MRCA <mrca at mailman.qth.net>
 Sent: Thursday, January 22, 2026 8:23:33 PM
 To: Military Radio Collectors Association <mrca at mailman.qth.net>
 Subject: [MRCA] R390A dropping resistor value         Guys,       I'm in the process of solid stating the power supply on a R390A. I need the value of the series resistor listed in the field change.        If anyone can help, I would appreciate it.       Best 73's       Bill N3WM

|  | Virus-free.www.avg.com |


  ______________________________________________________________
 MRCA mailing list
 Home: http://mailman.qth.net/mailman/listinfo/mrca
 Help: http://mailman.qth.net/mmfaq.htm
 Post: mailto:MRCA at mailman.qth.net

 This list hosted by: http://www.qsl.net
 Please help support this email list: http://www.qsl.net/donate.html

  ______________________________________________________________
MRCA mailing list
Home: http://mailman.qth.net/mailman/listinfo/mrca
Help: http://mailman.qth.net/mmfaq.htm
Post: mailto:MRCA at mailman.qth.net

This list hosted by: http://www.qsl.net
Please help support this email list: http://www.qsl.net/donate.html ______________________________________________________________
MRCA mailing list
Home: http://mailman.qth.net/mailman/listinfo/mrca
Help: http://mailman.qth.net/mmfaq.htm
Post: mailto:MRCA at mailman.qth.net

This list hosted by: http://www.qsl.net
Please help support this email list: http://www.qsl.net/donate.html


-------------- next part --------------
An HTML attachment was scrubbed...
URL: <http://mailman.qth.net/pipermail/mrca/attachments/20260126/c8b43f8c/attachment-0001.html>
-------------- next part --------------
A non-text attachment was scrubbed...
Name: R390A_mod_series_resistor_listed_in_the_field_change.jpg
