[ARC5] [Milsurplus] Data plate warping fix ?

[Michael Hanz]

Dr. Barry Ornitz wrote about this in several groups about twenty years
ago.  Do a search on "Barry Ornitz radio plastic" and the same with
"radio plasticiser" and you will get quite a few hits on his
methodology.  And of course he had the lab at Kodak to do material
analysis.  His conclusion was that you can't put the genie back in the
bottle.  The closest I've come without resorting to etched brass
material has been by using a a TLC 5500T credit card lamination machine
with a 15 Mil thickness credit card "pouch".  I had to get a better
machine to do it well - the first one I bought didn't get the thicker 15
Mil credit card material hot enough. Below is one of the results, this
for a WWII pulse analyzer.  (The original is on top...)



73,
Mike  KC4TOS
