[GreenKeys] Panel Help, Questions

[Ken Wiebe]

My 35 ASR panel has only Off line, Line, and Unattended. Plus buttons marked 'Aux receiver' and 'Local punch'.

See attd picture.

This panel is to the left of the keyboard and there are no other switches (the panel to the right of the keyboard, for example, is a blank panel).

The call control panel has cutouts for a few pushbuttons, but currently empty.

Everything I've read in the documentation seems to indicate this is a Private Line ASR. But I haven't seen this exact panel configuration in any of the documentation.

As for actual operation, the keyboard types locally whether set to Line or Unattended (Off line turns the power off completely).

The buttons don't have any effect. Of course Local punch isn't going to do anything without the reperforator hooked up.

But since I did not find a description of the operation of this type of panel, I was wondering if anyone could explain how it's supposed to work? For example, nothing labeled 'Local'. etc.

Thanks in advance.

Ken
