[R-390] TR: R-390 Mechanical Alignment

[Jacques Fortin]

Hello Bill,

My 1953 manual copy is spiral bounded, so not that easy to scan...
I made a photo (attached) of the related page, however.
No mention of the 2nd IF cam into.
The more recent TM11-856 and TM11-5820-357-35 are OK only if the following text is blanked out (or disregarded, whatever you like):

"The position of the second if cam shown in figure 90 (or 44) represents the correct position for high end of the band (the last three digits of the frequency indicator should read 999)"

Again, I do not understand where this sentence came from, as it just makes no sense.

73, Jacques, VE2JFE in Montreal
