[MRCA] Recieve antenna on Noisy Band

[mstangelo at comcast.net]

During the winter I operate the Moose and Squirrel from home. Sixty meter noise levels are quite high at noon. I am also usually the southernmost station and sometimes the northernmost stations are occasionally weak.

I have three antennas, an Inverted L against 35 radials that I can tune from 160 to 20 meters. I have a low 80 meter Inverted V that I can tune from 80 through 20 but is does not get out as well as my Inverted L. I also have a 20 meter vertical loop I can tune from 20 to 6 meters.

I recently rearranged my shack  so that I can easily switch antennas.

During today's M&S net the band was moderately noisy but I could barely hear KW1I the net controller. During receive I switched antennas as found whereas the receive signal was slightly lower the noise level was dramatically lower hence the readability significantly increase since the signal to noise ratio increased. I took pictures of on 7300 spectrum scope to show the difference. See attachments.

I suggest trying other antennas to impreove the signal to noise ratio. Just remember to switch back when transmitting.

Mike N2MS
-------------- next part --------------
A non-text attachment was scrubbed...
Name: 160M-Inverted-L.jpg
Type: image/jpeg
Size: 2464794 bytes
Desc: not available
URL: <http://mailman.qth.net/pipermail/mrca/attachments/20251216/97c6877f/attachment-0002.jpg>
-------------- next part --------------
A non-text attachment was scrubbed...
Name: 20M-Delta-Loop.jpg
Type: image/jpeg
Size: 2665832 bytes
Desc: not available
URL: <http://mailman.qth.net/pipermail/mrca/attachments/20251216/97c6877f/attachment-0003.jpg>
