[Milsurplus] MP 59-B ant mount question

[Thekan, Paul]

 The  MP 59 antenna mount is mounted on the back of the BC 939 ant tuner with the MP 47 when used with the BC 610  for the SCR 499 field set up.

On the attached jpg I have the MP 59-B mount that appears to be wider than the 939 tuner and about a inch too long in the back to mount up to the 939 tuner.

The mount looks like it was made for a different tuner than the 939 , or at least that's what it is looking like to me right now unless there is some other bracket I need to affix to the mount or the tuner to make this work.

The SCR 399/499 calls out for a MP 59-A mount. I've never seen a pic of one nor a photo showing it installed on a 939 tuner.

Anyone here ever seen a pic of one or even has a MP 59-A mount??

As always , thanks for any help or insight with this.

Paul
N6FEG
