John, W9DDD


> On Aug 30, 2022, at 10:50 AM, John W9DDD <w9ddd at tapr.org> wrote:
>
> I think you need 592-808-xxx series.  I just dug out my 592-800-000 to 593-000-000 book and it seems to hold some promise.
>
> These are sections for data speed equipment. They are largely fold out pages which don't have the section number at the top, so it's hard to figure out when you entered a new section.
>
> Off to sort it out, later.
>
> John, W9DDD
>
>
>> On Aug 30, 2022, at 1:49 AM, Joe Duszyński <joeduszynski1 at gmail.com> wrote:
>>
>> Well I have one, but there is no controller with it. :-(
>>
>> And I can't find the electronics portion description/schematics.
>> The info in question should be in
>> BSP 592-803-400TC And is basically what I'm looking for.
>>
>> Navy Nick has all the manuals in this series  592-803-100TC and
>> (700TC,701TC,702TC and 800TC
>> "All Except 592-803-400TC Unit (DPRE Type) - Wiring Diagrams "
>> Also missing is....
>> The cabinet wiring 592-830-400TC High Speed Tape Receiver Cabinet -
>> Wiring Diagrams"
>>
>> The controller is different from the BRPE punch.
>>
>> I did find the schematic for one of the DRPE cards Here............
>> https://www.navy-radio.com/manuals/tty/jh/ttyman9/drawings/303672.pdf
>> That schematic mentions schematic WD6050 which is not available either.
>> And the card matchs up to the Cabinet parts list/manual located here
>> https://www.navy-radio.com/manuals/tty/jh/ttyman6/TeletypeManuals/drpe/592-830-800TC-Iss1.pdf
>>
>> I can find the 592-803-XXXTC descriptions in the telcomarchive.com index but
>> can not find the 592-830-XXXTC descriptions there. Which leads me to think
>> that since they are Teletype (TC) pubs the BSP index would be less than a
>> complete copy of all that is available in Teletype stuff.
>>
>> All of the 592-83X-XXXTC don't show in the BSP index either but
>> Telcomarchive has copies of....
>> 592-831-100TC (200TC and 700TC) those are all for the BRPE Receiver
>> Set punch and Nick
>> does not have any of those or even the descriptions.
>> Just because it isn't in the BSP index doesn't mean it is not out there!! LOL!
>>
>>
>> JD
>>
>>
>>
>>
>>
>>
>>> On Mon, Aug 29, 2022 at 11:32 PM Eric Moore <mooreericnyc at gmail.com> wrote:
>>>
>>> I have asked a couple of times, here and elsewhere, the answer is always no. I hope to see one someday.
>>>
>>> I will have my BRPE running at 110 CPS at VCFMW in Chicago if anyone happens by.
>>>
>>> -Eric
