[GreenKeys] M28 cabinets - skin tight vs skin tight

[Paul Heller]

Interesting. Here are two of mine from the “to be checked out / to be restored” area of my shack. The first pic is what I was told by an authority is a skin tight 28 (whatever that means). The paper on it says “100WPM TELETYPE NEW”.  I don’t know what feed it was receiving that printed that, and am unsure what gears it really has in it. I was told it is ready for ITTY, but have not had a chance to try it and the paper makes me thing the speed is wrong.  Unlike a normal 28 it does not have a LESU. I am assuming the selector magnets hook directly to the loop, but I have not gone through the machine yet.




This second pic is closer to what you have, John. I was not able to identify this machine as a 28. It has a three speed gearbox it it. To the left of the keyboard is a lever (can’t see it in my photo) to switch speds. John, I can see there is a lever on yours as well. Is yours three speed?








Paul
W2TTY
i-Telex: 80003

ITTY:  		HTTP://INTERNET-TTY.NET:8000/ITTY
ITTY100:  	HTTP://INTERNET-TTY.NET:8010/ITTY100
AUTOSTART:  HTTP://INTERNET-TTY.NET:8030/AUTOSTART
EUROPE: 	HTTP://INTERNET-TTY.NET:8040/EUROPE
> On Mar 25, 2020, at 1:57 PM, John <John at tubetestingpros.com> wrote:
>
> Greetings Greenkeyers!
>
> Here is a shot of my 28 Compact - or rather I was told that this is a "Compact" - dunno for sure.
>
> Runs nicely, recent ITTY on the paper, rescued along with a larger hoard of machines last year.
>
> Cheers
>
> John KB6SCO
> Carson City
>
> On 3/25/2020 11:35 AM, Nick England wrote:
>> No, Teletype definitely wasn't consistent. They used "skin tight" or "skintight", "cover" or "cabinet", and "rack mount" or "rack mounted". And an LPC206 style KSR or RO was referred to as a "rack mounted set (skin tight cover)".
>>
>> You just gotta know one when you see one..
>>
>> The TT-176 is not a Compact - it is a rack mount and/or skintight
>>
>> Definitely a Compact is a Compact, even though it is narrow enough to put on a rack mount shelf.
>> The Compact KSR does not have a mechanical keyboard. It is a M32 electrical type (UGC-20) or photoelectric (UGC-77).
>>
>> Nick England K4NYW
>>
> <Mod28 Compact.jpg>______________________________________________________________
> GreenKeys mailing list
> Home: http://mailman.qth.net/mailman/listinfo/greenkeys
> Help: http://mailman.qth.net/mmfaq.htm
> Post: mailto:GreenKeys at mailman.qth.net
>
> 2002-to-present greenkeys archive: http://mailman.qth.net/pipermail/greenkeys/
> 1998-to-2001 greenkeys archive: http://mailman.qth.net/archive/greenkeys/greenkeys.html
> Randy Guttery's 2001-to-2009 GreenKeys Search Tool: http://comcents.com/tty/greenkeyssearch.html
>
> This list hosted by: http://www.qsl.net
> Please help support this email list: http://www.qsl.net/donate.html
> Message delivered to paul0926 at comcast.net
