[CW] July 1974 Popular Electronics = How to Break the 10-Words-Per-Minute Code Barrier

[David J. J. Ring, Jr.]

How to Break the 10-Words-Per-Minute Code Barrier
July 1974 Popular Electronics

When you think about it, the speed at which a human being is able to
accurately copy Morse code is limited by the same kinds of processes
that limit the speed at which binary data can be sent between electronic
transceivers (modems). Noise introduced into the signal at both the
transmitting and receiving ends or in the transmission path connecting
the two, degrades the ability of the receiver (electronic and human) to
discern between a "1" and a "0." It can take the form of electrical or
audio interference and distortion. Phase noise in the electronic realm
is sort of the equivalent of an irregular sending human hand that cannot
maintain equal dwell times for dits and dahs, thus making the
recognition of characters error-prone. The operational speed of
circuitry on an electronic assembly can also limit the speed at which
Morse code can be copied similar to how a particular person's gray
matter can limit his comprehension speed. One Navy lieutenant in the
article stated, "There may be a certain type of individual who can copy
fast code and a certain type who can't." Of course upon reading that
line I immediately thought of the joke declaring, "There are 10 types of
people in this world: Those who understand binary and those who do not."
To apply that here, the title could equivalently be interpreted as, "How
to Break the 2-Words-Per-Minute Code Barrier."

How to Break the 10-Words-Per-Minute Code Barrier
By Richard Humphrey

Lucky is the radio amateur who doesn't "plateau out" somewhere around
ten words-per-minute when he's learning code. There may be a fortunate
few who march right up to 20 or 30 wpm without a break, but most of us
make it to 10 wpm literally in a matter of days, then struggle for many
months to get up to 15 wpm solid copy so we can be sure of hacking 13
wpm when we go up for our General. Once definitely past the 10 wpm
"hump," progress is seldom a problem.

Hams aren't the only ones bothered by the CW plateau. The Navy, Army,
Coast Guard, and Air Force all have their difficulties in getting their
radio-operator trainees off the 10 wpm dime. When asked if the Army had
a problem, Colonel A.J. Sullivan in Washington said:

"Yes we do. Approximately 60% of trainees reach a hump somewhere between
10 and 13 words-a-minute. Our goal is to raise them to 15," he said,
"and often we're able to get them to go as high as 25 and 30
words-a-minute." Col. Sullivan went on to explain how the Army did it.
"The first way is to have the student and instructor analyze error
patterns and then determine remedial patterns to correct them in the
student.

"The second way," he continued, "is to analyze individual rhythm
patterns and make recommendations to improve these. The third thing is
to try and get these students to copy 'behind' one or two characters so
that they might be able to comprehend a whole word instead of a letter
at a time."

A spokesman for the U.S. Navy, Lt. Tim Mennuti, echoed Col. Sullivan.
"It takes three weeks to peak out," he said, "at which point the average
person has reached 12 to 14 words-per-minute." Mennuti added, "The
problem is that over 14 words-per-minute there are no breaks between
letters." It appears the Navy considers the "hump" serious since we
understand the training program is undergoing considerable revision.

Everyone interviewed agreed on one of two positions: either (a) the
plateau was caused by reaching a speed where you had to stop copying
letters and start copying words or (b) the "letter-to-word" transition
was a coincidence and the reason for the "hump" had to be found
elsewhere. The Navy seems to favor the latter view. "Apparently," said
Mennuti, "there's some psychology connected with this thing that we
didn't have before. What we're finding out," he explained, "is there may
be a certain type of individual who can copy fast code and a certain
type who can't."

Strangely, two things which might be expected to have had an effect on
an almost auditory process such as learning CW seem not to have affected
it at all: the increasing use of audio-visual aids in teaching and the
tremendous impact of television on those who have been coming into the
military. The generation which has been studying code for the past
several years are, say the experts, "picture" oriented rather than
"word" oriented. One might expect that hams and others cramming code
today would be having more trouble. But Col. Sullivan says the percent
of those hitting the "hump" hasn't changed "in the last 20 years."

Psychologists and authorities in the business of teaching brought up the
point when they were interviewed that getting past the 10 wpm plateau
wasn't a "learning" problem but a "fluency" problem. Obviously, they
said, if you can copy and send ten words-a-minute, you know the code.
The point was also made that gaining fluency in code might be similar to
gaining fluency in a foreign language. If you learn a foreign language
by "reading" it - in high school or college, for instance - you will
usually have tremendous difficulty in speaking (or understanding) the
language fluently. You will find that you translate from the foreign
tongue into your own language, absorb the information, form an answer,
in your own language, translate the answer into the foreign language,
and then say it. To gain any fluency whatsoever you must think in the
foreign language.

But how do you "think in code?"

Here, the experts and authorities as well as military instructors and
radio amateurs are more-or-less in agreement. Number one on everyone's
bugaboo list: don't sit down and learn the code before you start
listening to it! Many hams fall into this bottomless pit. The CW trainee
in the military has usually been sitting there for three hours with the
cans on his head listening to taped copy before someone tells him what
it is he's doing. Even so, six out of ten plateau out somewhere around
10 wpm, according to the Army. The attrition rate among radio amateurs
must be tremendous. One instructor put the problem this way:

"When you find yourself hearing dah-dit-dah-dit and saying 'Aha, that's
a C' and then writing it down, you're in big trouble. It's got to be
instantaneous," he said. "You hear it, you write it. No translating!"

The way you transcribe CW may also have a direct bearing on the 10 wpm
hump. Without exception, everybody agrees that the best way is to use a
typewriter. For two reasons. First, the mental attitude you have when
you learn to touch type is quite similar to what it should be in
learning code. You're not translating. You learn by rote that the right
forefinger goes there and the left forefinger goes here for this letter
or that letter. You're not falling into the bad habit of reading a
letter, looking for it on the keyboard, then hitting it.

Second, copying by hand in capitals will limit your speed to around 15
wpm. Long-hand script will only take you to 25 wpm or so. The only thing
limiting your code speed when using touch typing is your typing speed. A
40-wpm typing speed in only fair. A 40-wpm speed in copying code is very
good. (It's undoubtedly no coincidence that of the Air Force's 630 hour
CW course, 435 hours are devoted to "touch typing and transcribing
International Morse code with a typewriter.")

The various tapes and records on the market to teach you the code
undoubtedly have some value. The unanimous comment from radio amateurs
is that they'll memorize each tape or record after a few playings and
once this has happened the recording is useless. Tapes work out fine for
the military because they can afford thousands-of-hours of it so there's
little chance of copy memorization. Hams usually aren't so affluent.

What to do if you "studied" the code before you began listening to it?
You can try the Army's recommendation of "copying behind" to try to
progress from letter copying to word copying. Or you can try the method
used by a former Navy Chief Radio Electrician.

"My hump was around nine-a-minute," he says. "It made me mad. I just
kept at it. I copied until my eyes fell out. I even copied Russian and
Spanish code, though I didn't understand it. Later, aboard ship, they
tested me on taped copy and I made 9 words-a-minute.

To many would-be hams, all this insistence on an "antiquated" form of
communications is ridiculous. With FM, SSB, facsimile, and other things
to come in the future, they may be right. But CW is still the simplest
form of long-range communications. Because when you are using CW, you
can cut through QRM with modest power, a minimum number of components
with simple antenna, and troubleshooting and repairs can be made with
almost no training. CW is a unique ease of the Old Gray Mare being just
as good as she "used to be."
