[CW] Old QSK Box for Boat Anchors and Amplifiers

[D.J.J. Ring, Jr.]

Years ago, I was quite involved with a group of QSK operators, one was Dave
W4AX a retired Western Union Wire Chief from NYC he improved on a classic
design that everyone in the group used because compared to other units,
this one was fool proof and if it failed, no damage would be done to your
equipment.
[image: W4AX.jpg]
https://archive.org/details/w4ax_qsk_box_1975-08-03/mode/2up

The PDF for this is here:
https://archive.org/download/w4ax_qsk_box_1975-08-03/w4ax_qsk_box_1975-08-03.pdf

W9TO, Jim Ricks, W4AX, Dave Shafer, W4ZMQ, Marvin Carter, and others all
used this and it was excellent.  They used it with Alpha amplifiers.

I think it could be used with transceivers that have a "separate antenna
input" - or perhaps it could be modified for transceivers - 1975 we were
still using separate transmitters and receivers if we were serious about CW.

73
DR
