[ARC5] AN-104 aircraft antenna copper sheathing replacement.

[Michael Hanz]

As long as that antenna doesn't spend much time outdoors, that would
certainly work, Ken.  I think the original may have been a deep drawn
pressing, very amenable for copper.  Even iron, which was the first
generation I-104 sheath, was ductile enough.  The difficulty is when it
sits or flies in rain or salt spray.  Just something to consider.

- Mike  KC4TOS








On 1/11/2024 12:15 PM, Ken wrote:
> Mark: there is thin, pure, solid-copper sheeting available from art
> supply stores which would be very easily formed around a wooden core
> or "mold".
>
> You might consider trying that yourself, if you cannot find anyone who
> does that commercially.
> The stuff is a little thicker than aluminum foil, yet strong enough to
> hold together well even after being worked.
>
> I would wrap it around the core, solder it up the "back-side"  and
> form it around the top with a small hammer, if necessary, then connect
> it to the cable at the bottom.
>
> Ken W7EKB
>
>
> Sent via the Samsung Galaxy S21 5G, an AT&T 5G smartphone
>
>
> -------- Original message --------
> From: MARK DORNEY via ARC5 <arc5 at mailman.qth.net>
> Date: 1/11/24 08:52 (GMT-08:00)
> To: ARC-5 <arc5 at mailman.qth.net>, mrca at mailman.qth.net
> Subject: [ARC5] AN-104 aircraft antenna copper sheathing replacement.
>
> Anybody know of a vendor or company that makes or can make the copper
> sheath that covers the wood core of the AN-104 aircraft antenna?
>
> 73
> Mark D.
> WW2RDO
>
> “In matters of style, float with the current. In matters of Principle,
> stand like a rock. “.   -   Thomas Jefferson
>
> Sent from my iPhone
> ______________________________________________________________
> ARC5 mailing list
> Home: http://mailman.qth.net/mailman/listinfo/arc5
> Help: http://mailman.qth.net/mmfaq.htm
> Post: mailto:ARC5 at mailman.qth.net
>
> This list hosted by: http://www.qsl.net
> Please help support this email list: https://www.qsl.net/donate.html
>
> ______________________________________________________________
> ARC5 mailing list
> Home:http://mailman.qth.net/mailman/listinfo/arc5
> Help:http://mailman.qth.net/mmfaq.htm
> Post:mailto:ARC5 at mailman.qth.net
>
> This list hosted by:http://www.qsl.net
> Please help support this email list:https://www.qsl.net/donate.html

--
Michael Hanz - KC4TOS
