[ARC5] A.C. Modified BC-348

[Michael Hanz]

Schematic attached.  There were apparently two different rectifier tubes
used in the EP-298 Halli supply - initially a 5Y3GT, then a 6X5GT-G -
which has a separate cathode independent of the filaments.  It is not
hard to anticipate the eventual substitution of a 25Z5 to eliminate the
filament winding in the transformer...

No "safety" issues with that design.

On 8/28/2021 10:41 AM, J Mcvey via ARC5 wrote:
> A 25Z5 implies a "series string/ hot chassis circuit.
> The BC348 design does not lend itself very well  to a transformerless
> power supply.
> Then again, Hallicrafters was famous for grounding one side of the AC
> supply to the chassis!.
> This kind of mod is unsafe, IMO.
> However, safety did not seem to be a big concern "back in the day"...
>
