[ARC5] ARC-5 T-15 Bottom Freq, Loading.

[arc5@ix.netcom.com]

For anyone interested, this unmodified T-15 transmitter bottoms at 493KC. Powered from the MD7 at 27V primary and with a 1300pFd cap in series with ANT connection to the dummy load, it delivers 20 Watts to a 50-Ohm load with no external inductance from the TN-6.  I did not touch-up the PA tuning so might do better.
73 Dave AB5S
    Sent from my Ain't Smart Phone.
